Spank - Flare 24 Vibrocore 700c Wheels

SPANK - FLARE 24 VIBROCORE

RIM SPECIFICATION:

• HOLE COUNT: 28
• INNER WIDTH (mm): 24
• OUTER WIDTH (mm): 28
• PROFILE HEIGHT (mm): 16.5
• TYRE FIT: 35c to 62c or 1.5” to 2.3”

BUILD SPECIFICATION

• BUILD: Handbuilt
• HUB: SPANK HEX GRAVEL HUB J-TYPE
• SPOKES: J-Hook, tripple butted 2.2/1.8/2.0
• NIPPLES: Alloy external
• LACING: 3 cross lacing
• VALVE: F/V Presta
• TUBELESS: Tubeless taped & valved

NEW HEX DRIVE 102T HUB WHEELS

All SPANK Vibrocore and Radially Compliant Wheels, SPIKE and OOZY Wheels, and GRAVEL Wheels, have been upgraded to SPANK’s all new HEX DRIVE 102T Hub system, with 3.5° Engagement, and 6 Pawl, 18 contact point drive system. HEX hub wheels feature upgraded seals, “Bite Block” alloy freehubs, oversized bearings and alloy axles, and a unique flange design which minimizes dish in wheels and the resulting spoke tension range.
